Stairwell Hatch System 1200mm (with 2.5m to 3.5m Joist)

Stairwell Hatch System - Set

Stairwell Hatch System is designed to be lightweight for use on site whilst providing a large standing platform when installed. The system comprises of three parts; hinged and fixed framed glass reinforced plastic (GRP) hatches, ladder plate for securing a ladder and an adjustable telescopic joist.

Stairwell Hatch Systems are designed to provide full cover platforms over the stairwell opening in various combinations to suit your requirements. The system is designed to prevent falls through large stairwell openings whilst giving you full or partial access for operatives and materials.

This system allows fixed access to a ladder prior to a staircase being fitted. Openings next to party walls can be accommodated using a telescopic joist.
Ockwells Stairwell Hatch Systems have been independently tested to BS EN 12811-1:2003. Each Stairwell Hatch Grate has been tested to accommodate two persons standing on each panel in accordance with HSE RR342. The equivalent Uniformly Distributed Load (UDL) of 252 Kg/m2 or 2.47kN/m2.

Stairwell Hatch System Set comprised of:

• 1x Hatch Hinged Grate & Frame 900mm x 1200mm
• 2x Hatch Fixed Grate & Frame 900mm x 1200mm
• 1x Ladder Plate 450mm x 1200mm
• 1x Telescopic Joist 2500mm - 3500mm
• Smaller Telescopic Joist (1800mm - 2500mm) to suit smaller stairwell openings also available
